Ground Calcium Carbonate (GCC) for the Oil & Gas Industry

Acid-soluble rheological carrier and bridging agent for drilling, cementing and well completion
Ground calcium carbonate (GCC) is an acid-soluble mineral material specifically used in drilling fluids, cementing systems, and fluids for well completion and workover operations.
Thanks to a wide range of available particle-size distributions and high chemical stability, GCC helps to:
• control system density and rheology,
• manage fluid loss,
• reduce the risk of formation damage in the pay zone,
• optimize costs by using natural, environmentally acceptable material.
Key advantages of GCC for oilfield service
1. Acid-soluble density and loss control



Weighting with subsequent formation cleanup capability
GCC is used as a weighting material in water-based and oil-based drilling fluids, drill-in and completion fluids. The system density is increased to the required level for containing formation fluids, while the solid phase can be removed by acid treatment in the pay zone.

See products
1005 CALCIUM CARBONATE 5µm
2. Effective acid-soluble bridging agent

Monosized GCC blends form a controlled filter cake and temporary “bridges” in pores and fractures, reducing circulation losses in highly permeable and naturally fractured formations. After the operation is completed, these bridges are removed with acid, which allows formation permeability to be restored.

See products
1005 CALCIUM CARBONATE 5µm
3. Optimization of drilling fluids and completion fluids



Rheology and filtration control
Fine GCC fractions (D₅₀ ~ 5 microns) are used in drill-in and completion fluids to form a thin, tight filter cake and stable rheological properties. This increases wellbore stability and reduces the risk of stuck pipe and uncontrolled influxes.

Flexibility for different reservoir conditions
By adjusting the particle-size distribution, systems can be tailored to different reservoir types: from slightly fractured sandstones to highly permeable carbonate formations, minimizing irreversible damage compared with poorly soluble solid materials.

See products
1005 CALCIUM CARBONATE 5µm
4. Role of GCC in oilwell cement



Control of cement slurry density and yield
GCC is used as a filler and extender in cementing systems to reduce density, adjust rheology and filtration, especially when cementing weak or low-pressure formations.

Improved zonal isolation with the right formulation
Finely ground GCC helps improve particle packing in the set cement and reduce its permeability to fluids and gas. The dosage is selected based on laboratory testing results to maintain the required level of strength and durability.

See products
1005 CALCIUM CARBONATE 5µm
4. Cost efficiency and environmental acceptability



Natural and cost-effective mineral material
GCC is a widely available natural mineral with stable properties. Its use makes it possible to partially replace more expensive synthetic or poorly soluble materials in a number of applications (weighting, loss control, bridging) while maintaining the required technical performance of the systems.

Acid solubility and reduced long-term risks
Unlike inert solid materials, GCC can be deliberately removed from the formation using hydrochloric acid, which simplifies productivity restoration and reduces the risk of long-term formation plugging.

Non-toxicity and compliance with environmental requirements
Calcium carbonate is non-toxic and widely used in industries with strict regulatory standards. In oil and gas operations, its acid solubility and natural origin help combine technical efficiency with environmental compliance.

See products
1005 CALCIUM CARBONATE 5µm

Main application areas of GCC in the oil & gas industry

Drilling fluids
  • weighting in pay zones;
  • acid-soluble bridging agent for loss control.
  • formation of a controlled filter cake.
Completion and workover fluids
  • temporary isolation of highly permeable intervals.
  • loss control in workover operations.
  • preparation of the formation for subsequent acid treatment.
Oilwell cements
  • control of cement slurry density and rheology.
  • reduction of set cement permeability and improvement of zonal isolation (with an optimized formulation);
  • use in systems for cementing loss-prone zones.
Completion & Workover Fluids

  • Enhances fluid loss control by reducing permeability and seepage.

  • Stabilizes pressure conditions during workover operations.

  • Helps to seal micro-fractures and enhance well control.

Corrosion & Scaling Mitigation in Production Wells

  • Reduces acid-induced corrosion and prevents scale deposits in pipelines.

  • Ensures smooth flow conditions in production wells.

Enhanced Oil Recovery (EOR) & Reservoir Management

  • Used in water-based EOR techniques to improve oil displacement efficiency.

  • Optimizes reservoir pressure and permeability balance.

  • GCC grades depend on fluid compatibility and formation conditions.

Cemix's High-Quality GCC for Oil & Gas

Cemix offers high-purity GCC grades specifically designed for oilfield applications, ensuring optimal drilling performance, cement stability, and operational efficiency. Our products comply with industry standards, but requirements may vary depending on project specifications and regulatory conditions. Please contact us to specify the required certifications and compliance needs for your operations.

Get in touch with us for customized GCC solutions in oil & gas applications.
